AIR RELEASING VALVE 3/4 INCH BSP MALE THREADS

Powered quick inlet and outlet valve

Powered quick inlet and outlet valves are used in irrigation systems.

When the irrigation system is just starting to fill with water, the air valve can quickly

exhaust a large amount of air in the pipe; when the system is emptying the internal water,

the air valve inhales a large amount of air to eliminate the vacuum and drain the water smoothly.

The valve adopts an aerodynamic design with a powered quick inlet and outlet port;

it can avoid air accumulation or vacuum negative pressure formation,

and has good sealing performance at low pressure.

Application scenarios:

System ductwork : Prevents air from accumulating at high points of ductwork,

inflection points of slopes, and intersections of roads and rivers, eliminating negative pressure.

Water supply system : Prevents air accumulation and eliminates negative pressure.

Industrial system pipe networks and residential area pipe networks : to prevent air accumulation.

Maximum working pressure : 15 Bar

Sealing water pressure : 0.30 Bar

Exhaust volume(m3/h) : 0-280m³/h@0-0.35bar

Vacuum suction capacity (m3/h) : -280-0m³/h@-0.35-0bar
